01G360

Feature:

• Motor Voltage: 24/36 V DC
• Power Consumption: 750mA (Max. )
• Rotation Speed: 1.8°/sec with full load
• Solar Panel Size: Up to 460 Watt (1.7*2.0 m^2 / 40 Kgs)
• Overload Protection (Auto-Recovery)
• Reed Switch
• Limit Switches
• East to West rotating within 270°

Specification:
Model	01G360
Panel Size	Up to 460 Watt
Input Voltage	24 / 36 VDC
Power Consumption	750mA (Max.)
Rotation Speed	1.8° / sec with full Load
