Specification:

Model 01AQ200

Input 12VDC

Average Operating Current 2.0A

Gate Length 3M Max. (1.5 + 1.5)

Gate Weight 200kgs Max. (100 + 100)

Duty Cycle 20%

Overload Protection by Control Unit

Stroke Length 330mm

Drive ACME

Approx. Weight 4.5kgs

Approx. Dimension 670L x 450W x 235H mm

Control Box 01AQ-200S

Input	110/230V AC; 60/50HZ
RF Remote	433.92MHz w/Rolling Codes
Weight	2,6 kg
Dimensions	299L x 200W x 120H mm
Recharging Functions	Built In (12V DC Battery not included)

Up to 20mm/sec Speed
Compact & Powerful
Stream Lined Design
IP44
